OPERATING INSTRUCTIONS RH 200 Operation Regulating the travelling speed Travelling on level ground Regulate the travelling speed with " pedals (112 and 113, Fig. 2-82:) and " set the first (slow) range or the second (fast) range with switch (71, Fig. 2-83:). Turn speed regulator (56 and 66) fully clockvice (full-throttled position)
Change speed range only when the excavator is stationary.
Fig. 2-83:
Travelling uphill and downhill
Read and observe the "Travelling Safety instructions" chapter.
" Depress padals (112 and 113, Fig. 2-82:) fully to the limit stop. Fig. 2-82:
" Regulate the travel speed only with the engines speed control. When travelling downhill, the travel retarder valve acts as a speed limiter. The travel retarder valve works correctly if pedals (112 and 113) are fully depressed down to the limit stop.
Should the travelling speed become too high when travelling downhill release pedals (112 and 113) to stop the excavator.
