OPERATING INSTRUCTIONS RH 200 Operation Tab. 2-1
Assemblies resp. reservoirs
Measuring device
Remarks
Pump transfer gearbox
Dipstick (1, Fig. 2-58:)
Stop filling when the oil reaches the "max" mark on the dipstick (cf. Part 3, chapter "Pump transfer gearbox Checking the gearbox oil level/Filling in oil").
Engine
Dipstick (1, Fig. 2-59:
Stop filling when the oil reaches the "max" mark on the dipstick (cf. chapter "Engine - engine oil level/filling in oil").
Engine oil tank (Option)
Dipstick (2, Fig. 2-60:)
Stop filling when the oil reaches the "max" mark on the dipstick (cf. chapter "Engine - oil tank Checking the oil level in the engine oil tank/Filling in oil").
Fig. 2-60:
Fig. 2-58:
Fig. 2-59:
2-56
BA RH200(3 668 880.00)-EN
