OPERATING INSTRUCTIONS RH 200 Operation Fig. 2-47: No.
Element
Symbol
Function
121 Radio
(optional)
123 Lever
Locking console
the
left Lever vertical – console locked. Pushed forward – locking released. Console can be displaced.
124 Lever
Locking console
the
right Lever vertical – console locked. Pushed forward – locking released. Console can be displaced.
125 Warning lamp
Oil interval prolon- lamp is lit up, ging (left engine 1, flashes or pulsates, optional)
when one oil pump is running when both oil pump are running
126 Warning lamp
Oil interval prolon- lamp is lit up, ging (right engine 2, flashes or pulsates, optional)
when one oil pump is running when both oil pump are running
127 Antenna
(optional)
