OPERATING INSTRUCTIONS RH 200 Operation EMERGENCY STOP pushbuttons The entire electrical system is switched off with the EMERGENCY STOP pushbuttons.
!
on the righthand side at the counterweight This latter one is operate with the rope (3, Fig. 2-18:)
In an emergency, press the EMERGENCY stop. The EMERGENCY STOP pushbuttons are located !
in the control column in the driver's cab (31, Fig. 2-16:)
Fig. 2-18:
The electrical system of the excavator can be switched on after the EMERGENCY SHUTOFF buttons are activated. " Pull the buttons out Fig. 2-16:
!
in the control cabinet (2, Fig. 2-17:)
Windscreen washer The reservoir of the windscreen washing system (1, Fig. 2-19:) is installed in the cab module. For the reservoir capacity refer to the "Refilling quantities - Other" table.
Fig. 2-17:
Fig. 2-19:
BA RH200(3 668 880.00)-EN
2-15
