OPERATING INSTRUCTIONS RH 200 Operation Cab interior lamp
Servicing lighting
The interior lamp is switched on and off with switch (1, Fig. 2-12:).
Switch on the lamps in the modules with switches (95, Fig. 2-14:, 4, Fig. 2-13: and 3, Fig. 2-15:). Switch (95, Fig. 2-14:) is located in the control column in the driver's cab. Switch (4, Fig. 2-13:) is located beside the entrance door in the cab. Switch (3, Fig. 2-15:) is located beside the entrance door in the platform.
Fig. 2-12:
Switch position 0 - lamp off 1 - lamp on. The interior lamp can be used even if the electrical system is switched off. Therefore, switch off the interior lamp when leaving the machine. The batteries may be discharged if the interior lamp is left on for prolonged periods. The interior lamp is also switched on and off with switch (3, Fig. 2-13:).
Fig. 2-14:
Fig. 2-15: Fig. 2-13:
