OPERATING INSTRUCTIONS RH 200 Operation Demand control / Zero-flow regulation In the fine-control range, swivelling of the hydraulic pumps, and thus the variation of oil flow, are proportional to control lever and pedal valve travel. This means that during the work, the pumps supply only as much hydraulic oil as required to perform the working movement. In the neutral position of the control levers, the pumps are automatically swivelled to zeroflow. These special features offer the following advantages: !
reduced fuel consumption
!
minimum power losses
!
reduced temperature of the hydraulic oil
!
greater service life of hydraulic pumps and diesel engines.
Automatic engine speed reduction
Board-Control-System (BCS) The BCS is a data-evaluating and data-processing system whose function is to collect, evaluate and store data about the excavator's operating status and to display these to the operator. The BCS is based on a micro-processor. The measured values (actual values) supplied by sensors and transducers installed in the excavator are compared to preset nominal values. Out-of-limit conditions are displayed in the form of error messages in the cab. Critical operating conditions are additionally indicated by optical and acoustic warning signals. Further dedails are set out in the Board-ControlSystem operating instructions.
Electrical system The electrical system operates on 24 volts
If the control pedals and control levers and thus the Servovalves are not actuated for a period of 10 seconds or more (programable), the speed of the engines is automatically reduced to idling. Thisfunction is a further contribution to fuel economy.
