OPERATING INSTRUCTIONS RH 200 Inspection and servicing Pre-chamber
Pre-chamber
Check oil level
Checking oil level
(machine no. 200 083)
(from machine no. 200 089 onwards)
Check the oil level in the pre-chambers regulary.
The oil level in the pre-chambers is visually at the inspection glas (3, Fig. 3-100) in expansion reservoir (1).
" Unscrew plug (6, Fig. 3-99:).
The oil level should reach up at least to the middle of the inspection glas (3). Top up with gearbox oil, if required.
The oil level should reach up to the lower edge of the opening. Top up with oil if required. " Unscrew breather valve (3) and fill in oil through the opening until it flows out of the opening of plug (6). " Screw breather valve (3) and plug (6) back in place.
Fig. 3-100
Fig. 3-99:
BA RH200(3 668 880.00)-EN
3-89
