OPERATING INSTRUCTIONS RH 200 Inspection and servicing Electronic excavator control
Pedal
Joystick
Apply a thin layer of hydraulic oil regularly on the control spools of the pedals (arrows, Fig. 3-96:) to prevent jamming of the control spools.
Apply a thin layer of hydraulic oil regularly on the control spools of the joysticks (arrows, Fig. 3-95:) to prevent jamming of the joysticks.
Fig. 3-96: Fig. 3-95:
Make sure the hydraulic oil does not flow down along the control spools into the electronic control circuits where it might cause damage.
3-86
Make sure the hydraulic oil does not flow down along the control spools into the electronic control circuits where it might cause damage.
BA RH200(3 668 880.00)-EN
