OPERATING INSTRUCTIONS RH 200 Inspection and servicing Hydraulic oil can also be filled by means of the service station (Fig. 3-90:).
Filling in hydraulic oil Fill in hydraulic oil through the return-flow filters.
" Unscrew cap of express coupling (10).
" Fill in hydraulic oil through the opening until the oil level lies between the ½ and the ¾ marks of the inspection glass (1, Fig. 3-89:) (oil grade cf. "Refilling quantities - Oil").
" The use of the hose line is described under "hose line for oil and cooling-lequid changes". Connect filling hose express coupling of the service vehicle. Fill in hydraulic oil until the oil level lies between the ½ and the ¾ marks of the inspection glass (1, Fig. 3-89:) (oil grade cf. "Refilling quantities - Oil").
Fig. 3-88:
Fig. 3-90:
" Remove cap (19, Fig. 3-88:).
" The oil level is also displayed on the BCSscreen (Fig. 3-91:). " Vent the hydraulic system. " Check the oil level in the hydraulic oil reservoir. Top up with oil, if required. " Unscrew the hose line. The express coupling closes automatically. " Screw protective cap back in place.
Fig. 3-89:
" Vent the hydraulic system. " Check the oil level in the hydraulic oil reservoir. Top up with oil, if required.. " Refit cap (19, Fig. 3-88:).
Fig. 3-91:
BA RH200(3 668 880.00)-EN
3-83
