OPERATING INSTRUCTIONS RH 200 Operation Working When released, all control levers for working operation return automatically to position "0".
Level a surface only in the bucket's digging direction. Never "beat" or "sweep" with the bucket.
Loading bucket: Close bucket completely before beginning to dig. Do not level off a surface with the front shell of the bucket open.
Raising and lowering the boom
Fig. 2-100:
To raise the boom: pull control lever (116, Fig. 2-100:) backwards.
Filling and emptying the bucket or the backhoe
To lower the boom: push control lever (116) forwards.
To fill/tip back the bucket: shift control lever (116) to the left.
To lower the boom with pressure: depress button (103) and push control lever (116) forwards.
To empty the bucket by dumping/tipping: shift control lever (116) to the right.
Extending and retracting the bucket or backhoe bucket stick To extend the stick: push control lever (115) forwards. To retract the stick: pull control lever (115) backwards.
Opening and closing the bottom-dump bucket To open the bucket: press pedal (111) forwards or press button (117) to the left. To close the bucket: press pedal (111) backwards or press button (117) to the right.
To retract the stick with pressure: (only on bottom-dump bucket equipment) depress button (102) and push control lever (115) backwards.
