OPERATING INSTRUCTIONS RH170 Operation Control panel
Ventilation and heating
(Fig. 2-86:)
Ventilation (fresh air) Shut off block valves (2 and 3, Fig. 2-87:) Levers in position “ 0 “ Turn heating control knob (5, Fig. 2-86:) to minimum (heating performance = 0) Turn rotary switch (6, Fig. 2-86:) to the desired fan intensity (steps 1 - 3).
Fig. 2-86:
1
Indicator lamp
heating ON
2
Indicator lamp
blower ON
3
Indicator lamp
heating
4
Indicator lamp
cooling
5
Switch
heating ON
6
Switch
blower ON
7
Indicator lamp
blower level 3
8
Indicator lamp
blower level 2
9
Indicator lamp
blower level 1
2-68
Fig. 2-87:
Adjusting the heating performance Open block valves (2 and 3, Fig. 2-87:) Levers in position “ I “ Turn knob (5, Fig. 2-86:) to the right depending on the heating performance desired. If greater amounts of warm air are needed, switch on the fan with rotary switch (6, Fig. 2-87:).
