OPERATING INSTRUCTIONS RH170 Operation (Fig. 2-59:) (Options. Depending on the options ordered with the machine, the described elements can be found on different positions on the control column). Symbol
Funktion
Pos. Benennung 211 Warning lamp
Oil interval prolong- Lamp is lit up, ing (left engine 1) flashes or pulsates,
212 Warning lamp
Oil burning left engine 1)
Lamp lits up green, when the oil burning system is ready to operate. Additional a fault code is indicated.
213 Warning lamp
Oil burning left engine 1)
Lamp lits up red, when a fault occurs in the oil burning system. Additional a fault code is indicated.
214 Warning lamp
Oil interval prolong- lamp is lit up, ing (right engine 2) flashes or pulsates,
215 Warning lamp
Oil burning right engine 2)
Lamp lits up green, when the oil burning system is ready to operate. Additional a fault code is indicated.
216 Warning lamp
Oil burning right engine 2)
Lamp lits up red, when a fault occurs in the oil burning system. Additional a fault code is indicated.
BA RH170(3 725 031.00)-EN
when one oil pump is running when both oil pump are running
when one oil pump is running when both oil pump are running
2-55
