OPERATING INSTRUCTIONS RH170 Operation (Fig. 2-46) No.
Element
Function
30
Lamp
Illuminates the control column.
31
Button
Emergency OFF
Symbol
Shuts off the whole electrical system, shuts the engines off.
32
Key-switch
Switches the electrical system on and off.
33
Buzzer
Gives acoustic warning signals if a fault is reported, display of the BCS shows “ENGINE STOP”. If the buzzer (33) sounds and the BCS indicates a fault message together with “ENGINE STOP”: - Lower the equipment to the ground, - shut off engine / engines immediately. Inform the responsible service personnel to rectify the fault. In this way major damages can be avoided.
BA RH170(3 725 031.00)-EN
The buzzer (33) continues to sound until the fault has been rectified. Coolant level engine 1 (left) and / or engine 2 (right), too low;
Engine oil pressure engine 1 (left) and / or engine 2 (right), too low;
Engine oil temperature engine 1 (left) and / or engine 2 (right), too high;
Engine oil level engine 1 (left) and / or engine 2 (right), too low;
Distributor gearbox temperature 1 (left) and / or 2 (right) too high;
Distributor gearbox 1 (left) and / or 2 (right) contaminated;
Temperature of one or more swing pumps (1, 2, 3 and / or 4) too high;
One or more swing gearboxes (1, 2, 3 and / or 4) contaminated;
One or more swing motors (1, 2, 3 and / or 4) contaminated;
2-29
