OPERATING INSTRUCTIONS RH170 Operation Windscreen washer
Trainer's / instructor's seat
The reservoir of the windscreen washing system (1, Fig. 2-26:) is installed in the cab module. For the reservoir capacity refer to the "Refilling quantities - Other" table.
For driver training / instructing purposes it is often required that a trainer / instructor accompanies the driver in the cab. For the safety of the trainer / instructor during excavator operation the cab is equipped with a second seat. This seat is installed behind the driver's seat (arrow, Fig. 2-27:). Sit down on this seat and do not forget to fasten the seat-belt (if installed). Do not leave this seat during the training / instruction session and /or as long as the machine is in operation.
Fig. 2-26:
Fig. 2-27:
2-18
BA RH170(3 725 031.00)-EN
