OPERATING INSTRUCTIONS RH170 Inspection and servicing Engine oil reservoir (optional), checking the oil level / topping up Park the machine on a horizontal surface and secure against inadvertent movements. Shut off engines. Unlock the oil dipstick (3, Fig. 3-15:) and withdraw. Wipe oil off the dipstick with a clean, lintfree cleaning rag and re-insert. Draw out dipstick a second time. The oil level should lie at the mark. If the oil level is below, the engine oil is filled in from the service station (Fig. 3-16:) through
Fig. 3-15:
- express coupling (6) for the lefthand engine oil reservoir, - express coupling (7) for the righthand engine oil reservoir. Top up until the inspection glas (1, Fig. 3-15:) is complete filled with oil.
Fig. 3-16:
