OPERATING INSTRUCTIONS RH 40 E Inspection and servicing Cleaning jobs
Fastening and securing elements
Prior to commencing work, clean your working area, if necessary and possible, with a stream jet (rubber parts and electric components with compressed air - refer to information label).
Check fastening and securing elements, e.g. bolts, nuts, washers, before using them again.
Use only lint-free cleaning rags when working on the hydraulic system or the engine.
Spare parts
Cleaning agents and solvents may give off harmful, readily flammable vapours. Never work with such agents except on well ventilated premises; never inhale the vapours and never smoke. Prevent solvents and cleaning agents from coming into contact with your skin. Wear gloves. Observe the instructions on the packaging. Handling flammable liquids
Replace any damaged parts.
Use only the original sparts parts of TerexGermany. They are the only ones to fulfill the technical specifications of the machine. Handling oils and greases Hot lubricant or hydraulic oil emerging uncontrolled from the system may result in severe burns. Never set foot withing reach of the emerging oil jet.
When handling flammable liquids:
Avoid contact with the skin. Wear gloves and firm protective clothing.
!
never smoke,
Used oil may be harmful to the skin.
!
keep away from unshielded light sources and naked flames,
Clean soiled skin thoroughly with warm soapy water and apply a barrier cream. Never use fuels or solvents for cleaning the skin.
Fuel and other consumables often have low flash points and are readily ignited. Never attempt to extinguish burning liquids with water.
If you have swallowed any oil, avoid vomiting but consult a doctor immediately.
Use: !
dry powder,
!
carbon dioxide or
!
foam extinguishers.
Water used for extinguishing purposes would vapourize instantaneously on contact with burning substances and spread burning oil, for example, over a wide area. Water generates short circuits in the electrical system, possibly producing hazards. Notify the fire brigade.
3-4
Visisble oil losses Have any visible leakage repaired immediately. Escaping oil is an environmental hazard. Soak up any oil that has escaped with a binding agent. Sweep up binding agent and dispose of it separately from other waste.
BA RH40E(3 664 930.00)-EN
