OPERATING INSTRUCTIONS RH 40 E Operation Load-hooks on backhoe buckets.
Lifting capacity of the load hook
In order to be able to use the excavator with backhoe attachment also for short lifting operations, the backhoe buckets are available with welded load-hooks (Fig. 2-58: and Fig. 2-59:) (optional equipment).
The maximum lifting capacity of the load-hook is indicated besides the hook (Fig. 2-58: and Fig. 2-59:).
Read and observe "Lifting-gear operation - Safety instructions".
Lifting capacity of the excavator The admissible lifting capacity as a function of the working range is set out in the load table, see "Technical Data".
Switch on your overload warning system.
Fig. 2-59:
Fig. 2-58:
BA RH40E(3 664 930.00)-EN
2-61
