OPERATING INSTRUCTIONS RH 40 E Operation TRANSPORTING THE MACHINE 2804419
The partly dismantled excavator can now be transported on a semi ow-bed trailer (low-bed trailer with front platform) (Fig. 2-46:).
Transport - Safety instructions The machine must be loaded and transported only after all safety regulations have been observed and complied with. Entrust loading and transporting of the machine to a company experienced in the transport of heavy equipment. The responsability for loading and transporting lies with the transport company or their representative. Remove oil, grease, soil, mud, snow, ice and other materials from the excavator's crawler tracks and from ramps and loading platforms of the transport vehicle to minimize slipping.
Fig. 2-46:
Secure the transport vehicle against rolling away.
The dismantled components and modules must be transported on vehicles or low-bed trailers of sufficient size and carrying capacity.
Use only tying equipment of sufficient strength (the weights and dimensions of the excavator are set out in the "Technical specifications").
Loading the excavator:
Transport The dimensions and the service weight of the fully assembled excavator do not allow the excavator to be transported in an undismantled state on a low-bed trailer over public roads. Therefore, the following components and modules must be dismantled beforehand: !
counterweight
!
driver's cab
!
excavating tool (loading bucket, backhoe bukket)
!
stick
!
boom
" Lower the front platform of the low-bed trailer down to the ground. " Uncouple the front part of the low-bed trailer and pull it away with the truck tractor. " Drive the excavator (without counterweight) from the front over the lowered platform with the tracks straddling the low-bed trailer. Align the machine properly in the longitudinal and the transverse direction (Fig. 2-47:).
Fig. 2-47:
BA RH40E(3 664 930.00)-EN
2-49
