OPERATING INSTRUCTIONS RH 40 E Operation Adjusting the heating performance
VENTILATION AND HEATING 2804412
Ventilation
" Slide lever (91, Fig. 2-32:) forwards depending on the heating performance desired. The foremost position gives maximum heating power.
(fresh air) " If greater amounts of warm air are needed, switch on the fan with rotary switch (60, Fig. 2-31:).
Fig. 2-31:
" When the engine is stationary, turn keyoperated switch (72, Fig. 2-31:) to position 1
Fig. 2-32:
" Slide heating control lever (91, Fig. 2-32:) backwards (heating power = 0). " Turn rotary switch (60, Fig. 2-31:) to the desired fan intensity (steps 1 - 3).
BA RH40E(3 664 930.00)-EN
2-41
