OPERATING INSTRUCTIONS RH 40 E Operation Driver's seat
Adjusting the lumbar support
The driver's seat (Fig. 2-9:) can be adjusted in inclination, height and fore-and-aft position. The seat suspension can be adapted to the driver's weight.
The backrest is equipped with an upper and a lower air chamber.
Never adjust the seat while driving. Concentrate on the road to avoid accidents. Before carrying out any seat adjustments: - stop the machine - set the control lever to "0"
Pull knob (7) upwards - the lower chamber is inflated with air Pull knob (3) upwards - the upper chamber is inflated with air Push knobs (3 and 7) downwards - the air chambers are deflated
Adjusting the seat cushion Adjust the inclination of the seat cushion with handle (4). Bring the seat cushion into the desired position by moving the body forwards or backwards. Release handle (4).
Adjusting the armrests The armrests can be raised or lowered as required. To adjust the armrest inclination, turn knobs (6) to the right or left.
Fore-and-aft position The fore-and-aft position of the seat can be adjusted with lever (1). Pull lever (1) upwards, slide seat to the desired position and allow lever (1) to engage.
Adjusting the seat suspension Fig. 2-9:
Adjusting the backrest Adjust the inclination of the backrest with handle (5) verstellen. Lean against the backrest or move your body forwards to bring the backrest into the desired position. Release handle (5).
The seat suspension can be steplessly adjusted with lever (2). Higher weight - Pull knob (2) upwards (hard springs). Lower weight - Push knob (2) downwards (soft springs) Optimal setting +/- 50 mm swing.
