OPERATING INSTRUCTIONS RH 40 E Inspection and servicing Filling in new oil / Topping up
Gearbox venting
"
The gearbox is vented through breather filter (2, Fig. 3-76:). Clean breather filter in accordance with the servicing plan.
Unscrew plug (4, Fig. 3-76:) and fill in new oil.
" Check oil level with dipstick (1, Fig. 3-76:). " Screw in plug (4) again.
" Unscrew breather filter (2), clean in white spirit or paraffin oil and blow dry with compressed air. " Screw breather filter (2) back in place.
Output pinion Grease bearing regulary. " Fill in approximate 20 g. grease (4 – 5 strokes) through grease nipple (5, ) by means of a hand grease pump.
Fig. 3-76:
Fig. 3-77:
BA RH40E(3 664 930.00)-EN
3-73
