OPERATING INSTRUCTIONS RH 40 E Inspection and servicing Checking / cleaning the filter element
" Clean recipient (1) and filter housing (4). " Loosen flange (2).
Replace filter element (6, Fig. 3-41:) only when the suction resistance is too high.
" Take off recipient (1) and clean with diesel fuel " Check cover sealing and replace, if necessary. " Attach recipient (1) with flange (2) at filter housing (4). Check for proper sealing.
Fig. 3-41:
" Loosen venting plug (9) and leave drain valve (3) open until the reservoir is completely empty.
Collect escaping liquid in a recipient suitable for diesel fuel and discard without polluting the environment. " " Remove cover (5). " Remove spring holder (7) and filter element (6) from filter housing (4). " Check / replace filter element (6) " Clean filter housing (4) using diesel fuel. " Check cover sealing and replace,if necessary. " Insert filter element (6) and spring housing (7) into filter housing (4). " Fasten cover (5) on filter housing (4).
Check for proper sealing.
3-52
BA RH40E(3 664 930.00)-EN
