OPERATING INSTRUCTIONS RH 40 E Inspection and servicing Fix an instruction sticker (Fig. 3-1:): !
in the cab,
!
on the hydraulic oil tank and
!
on hydraulically-operated attachment.
Fig. 3-1:
" Start up the machine. Check level in hydraulic tank according to servicing plan. " The hydraulic fluid may dissolve deposits in the hydraulic system. So change all filters 30 - 50 operating hours after making the change. Make further filter changes according to servicing plan. " Sample the hydraulic fluid after 30 - 50 operating hours and send in for analysis. (See section: "Environmentally compatible hydraulic fluid, sampling").
BA RH40E(3 664 930.00)-EN
Environmentally compatible hydraulic fluid - Sampling Complete sets are compiled for hydraulic fluid analysis. They contain all necessary parts. !
Sets are available from the Terex Germany Spare-Parts Service: Part-No. 1 465 077.
!
Hydraulic fluid analyses are performed by: WEARCHECK GmbH Bahnhofstraße 75 D-83098 Brannenburg
!
After 30 - 50 operating hours with environmentally compatible hydraulic fluid, take a sample of the hydraulic fluid. Send this sample in to the above address for analysis. The company will then notify you of the result of the analysis.
!
After this, Terex Germany recommends sending in a sample for analysis every 1000 operating hours or once a year. It is essential that the hydraulic fluid should be analysed not later than after 3000 operating hours.
!
The results of the analysis show whether the hydraulic fluid is still serviceable and the changing interval can be extended. In case of questions contact the Terex Germany Service.
3-11
