OPERATING INSTRUCTIONS Inspection and servicing
Check every week,
In the event of deviating pressure values, shut off the engines and check the central greasing system.
whether the oil pressure indicated by pressure gauge (4, Fig. 3-135:) is 60 bars.
Lower oil pressure means that not all of the greasing points are supplied with grease.
Checking the greasing pressure
Higher oil pressure may cause bursting of a greasing line.
Always refill the grease container in time to avoid air from penetrating into the greasing system. Air in the greasing may cause malfunctions.
Fig. 3-135:
The necessary greasing pressure of 320 bars for the superstructure and 180 bars for the undercarrige is generated by means of a pressure translator. The greasing pressure for the superstructure is indicated by pressure gauge (9, Fig. 3-135:) the greasing pressure for the undercarriage by the pressure gauge (22, Fig. 3-136:).
Fig. 3-136:
3-102
Update to version .01, see pages 3-25 and 3-93a
