BI015807
OPERATING INSTRUCTIONS Inspection and servicing PUMP TRANSFER GEARBOX
Changing the gearbox oil 27323098
Read and observe: "Inspection and servicing - Safety instructions.
Drawing off oil The gearbox oil is drained with the service station (Fig. 3-100:) through
Read and observe: "Inspection and servicing Safety instructions. Shut off the engines The gearbox housings may be hot, too. Secure the machine as described in the "Securing the machine" section. Protect the skin from contact with gearbox oil. Skin contact with cooling liquid is a potential health hazard. Wear protective gloves and firm working clothing.
§
express coupling (4) for the lefthand pump transfer gearbox
§
express coupling (5) for the righthand pump transfer gearbox
Checking the gearbox oil level / Topping up with oil Park the machine as described in the "Securing the machine" section. Ü Pull out dipstick (1, Fig. 3-99:), wipe and push in again. Ü Pull out dipstick (1) a second time.Oil level should lie between the two dipstick markers. Top up with oil if required. Ü Push in dipstick (1) again.
Fig. 3-100:
Ü Unscrew cap of express coupling and connect hose line of the service vehicle. The hose line and its use are described in the "hose line for oil and cooling liquid change" section. Ü Remove hose after the oil has been drawn off. The coupling closes automatically. Ü Screw on protective cap.
Fig. 3-99:
3-86
Update to version .01, see pages 3-25 and 3-93a
BA RH400(3 659 450.00)-EN
