OPERATING INSTRUCTIONS RH 400 Inspection and servicing AIR-INTAKE SYSTEM
Main filter elements 3659728
Read and observe the "Engine Safety instructions" chapter.
Risk of injury caused by rotating or hot parts of the engine.
Insufficient air-intake performance, caused by acontaminated main filter element, is displayed on the BCS-screen (Fig. 3-36:). Clean or renew main filter elements only if the BCS displays a warning on the screen (Fig. 3-36:) with the engines running at high speed or if the vacuum-meter (8, Fig. 3-37:) has changed to “RED“.
Shut off the engines before working on the airintake system. Secure the machine as described in the "Securing the machine" section. Do not start the engine when parts of the air-intake system have been detached. Engine damage may occur if the engine is allowed to draw in unfiltered air. Each engine is equipped with six dry-air filters (Fig. 3-35:) consisting of main and safety filter element.
Fig. 3-36:
Fig. 3-37: Fig. 3-35:
3-51
Update to version .01, see pages 3-25 and 3-93a
