BI015807
OPERATING INSTRUCTIONS RH 400 Inspection and servicing Oil filters
Replacing the oil filter
Read and observe: "Inspection and servicing – Safety instructions".
Carry out servicing of the full-flow oil filters (1, Fig. 3-23:) in accordance with the engine operating instructions.
Risk of scalding from hot engine oil.
The filter housing may also be hot.
Wear protective gloves and firm working clothing.
Collect escaping oil and discard with-out polluting the environment
Fig. 3-23:
Replacement Ü Shut off the engines Ü Unscrew the filters Ü Install new filter together with slightly oiled sealing ring and tighten by hand. Thereafter Ü Allow engines to run at idling for a short while and check filters for tightness and leaks before shutting off the engines. Ü Check oil level after abt. 10 minutes and top up, if required.
3-43
Update to version .01, see pages 3-25 and 3-93a
BA RH400(3 659 450.00)-EN
