OPERATING INSTRUCTIONS Inspection and servicing
Filling in engine oil through the service station Fill in engine oil through §
express coupling (8, Fig. 3-17:) for the lefthandengine
§
express coupling (9) for the righthand engine
until the oil level has reached the "max." mark (Fig. 3-17:) on dipstick (1, Fig. 3-19:). Ü Unscrew cap of epress coupling and connect filling hose of the service vehicle. Fig. 3-19:
Ü Start the engines and allow to run at idling for abt. 2 minutes. Ü Check oil level at dipstick (1, Fig. 3-18:) and top up with oil to the "max" mark (Fig. 3-19:) if required. Ü Remove the filling hose. The epress coupling closes automatically. Ü Screw on protective cap.
Fig. 3-17:
The hose line and its use are described in the "hose line for oil and cooling liquid change" section.
Fig. 3-18:
3-40
Update to version .01, see pages 3-25 and 3-93a
