OPERATING INSTRUCTIONS RH 40 F Operation Using the refuelling system " Unscrew cap (16, Fig. 2-37:) from express coupling (17). " Attach filling hose (18) to express coupling (17) and introduce into the fuel barrel. The electrical pump of the refuelling system is switched on with key-switch (14).
Switching the electrical system on and off The electrical system is switched on with keyswitch (32, Fig. 2-38:). Insert key into key-switch and turn to the right.
Switch on electrical pump only after the filling hose with the micro-filter has been immersed into the fuel barrel.
Fig. 2-38:
Fig. 2-37:
It is recommended to use a micro-filter in the filling line.Fuel should always be filled in through a screen.
BA RH40F(3 668 020.01)-EN
2-45
