OPERATING INSTRUCTIONS RH 40 F Repair work Connecting the jumper cables " Connect the red jumper cable to the positive pole of the empty battery (1,Fig. 4-1:), then to the positive pole of the charged battery (2). " Connect the black jumper cable first to the negative pole of the charged battery (3), then to the negative pole of the empty battery (4). Explosion hazard When the negative terminal is connected to ground, a strong current flows through the jumper cable.
Starting up the engine " Start up the engines of the supplying machine and run at high speed. " Start up the engine of the receiving machine. If the engine fails to start up after 15 seconds, wait for one minute and thenstart again. " When the engine has started up, continue running both machines in no-load operation for about two or three minutes with the jumper cables still connected.
The sparks produced in the contact area can ignite the gases emanating from the discharged battery.
Disconnecting the jumper cables
The negative terminal must therefore be connected to ground at a place as far away from the discarged batteríes as possible.
" Positive pole at the supplying machine (2)
" Negative pole at the receiving machine (4) " Negative pole at the supplying machine (3)
" Positive pole at the receiving machine (1) " For machines with electronic modules: - Run engine for about half an jour at low speed. The batteries are partially charged. - Shut off engine - Make all electrical connections to the modules. - Start up engine without jumper cables.
Fig. 4-1:
