OPERATING INSTRUCTIONS RH 40 F Inspection and servicing Filling in new oil / Topping up
Gearbox venting
"
The gearbox is vented through breather filter (2, Fig. 3-81:). Clean breather filter in accordance with the servicing plan.
Unscrew plug (4, Fig. 3-81:) and fill in new oil.
" Check oil level with dipstick (1, Fig. 3-81:). " Screw in plug (4) again.
" Unscrew breather filter (2), clean in white spirit or paraffin oil and blow dry with compressed air. " Screw breather filter (2) back in place.
Output pinion Grease bearing regulary. 3
" Fill in approximate 50 cm / 1,7 oz grease through grease nipple (5, Fig. 3-82:) by means of a hand grease pump. Fig. 3-81:
Fig. 3-82:
BA RH40F(3 668 020.01)-EN
3-77
