G - CONTROLS
CASE Joystick controls with 14-pins connector The controls on the operating machine joystick can be used to control the snow blower’s hydraulic functions as per below instructions:
RIGHT SIDE (1) Flap hydraulic movement control (2) Proportional aux (3) Park brake (4) Float (5) Ride control
LEFT SIDE (1) Multi func # 4 (2) Horn (3) Multi func #3 (4) Chute hydraulic rotation control (5) 2 Speed
41 - En
