CASE JOYSTICK CONTROLS WITH 14-PINS CONNECTOR

CASE Joystick controls with 14-pins connector

The controls on the operating machine joystick can be used to control the snow blower’s hydraulic functions as per below instructions:

RIGHT SIDE

(1) Flap hydraulic movement control (2) Proportional aux (3) Park brake (4) Float (5) Ride control

LEFT SIDE

(1) Multi func # 4 (2) Horn (3) Multi func #3 (4) Chute hydraulic rotation control (5) 2 Speed
