4 - ASSEMBLY
4 - ASSEMBLY Installation
Kit installation 1. Install the two hydraulics connectors (3) to the top of the solenoid valve (2).
LEIL17WHL0067AB
1
LEIL17WHL0068AB
2
LEIL16WHL1441AB
3
2. Install the two 45° elbows (10) on the solenoid valve (2): • One 45° elbow (10) on the side of the solenoid valve (2) • One 45° elbow (10) on the bottom of the solenoid valve (2)
3. Install the solenoid valve bracket (1) on the two studs welded on the front chassis. Install the washers (4) and the nuts (5) to fix the bracket (1) to the front chassis.
10 EN
