LUBRICATION
FUEL SYSTEM SERVICE SPECIFICATIONS Draining water and sediment from the fuel tank.............................. Every 50 hours Draining water from the water separator ......................................... Every 50 hours Fuel filter replacement................................................................... Every 500 hours Fuel tank capacity ........................................................................340 litres(90 gal.) Type of fuel....................................................................See “Fluids and lubricants”
DRAINING WATER AND SEDIMENT FROM THE FUEL TANK
DRAINING WATER FROM THE WATER SEPARATOR. A
1
CD00E174 CD00E107
Have a container ready to collect the drained contaminants. Open the drain valve located at the bottom of the tank and drain the accumulated sediment and water. After draining, close the drain valve.
When the float reaches the level line (A) Loosen the drain plug (1) and drain the water and sediment. When the float (2) settles on the bottom, tighten the drain plug (1). Verify that there are no fuel leaks.
!
WARNING: Completely wipe off any spilled fuel. It may cause a fire.
151
