LUBRICATION/FILTERS/FLUIDS
ENGINE HOOD 1. HANDLE 1
Push lock button and raise hood to open. Open hood until support strut locks full open. 2. ASSIST CABLE
2
To close hood, pull down on assist cable while pushing strut release tab.
MAINTENANCE GENERAL Always check oil level and drain or fill all the reservoirs with the engine off and machine on a flat ground.
Maintenance and lubrication chart decal is located on the rear of the cab in the lower left corner.
The intervals specified here refer to normal operating conditions. During the initial period of use (run-in) and under severe working conditions, the servicing intervals need to be shortened. Consult your Case Dealer for more information. Drain the engine oil immediately after shutting off the engine while the oil is warm and flows more easily. After refilling system the oil should be checked only after engine has been run at low idle for a few minutes. This procedure insures that the oil cooler, filters, lines, etc., are completely full before the oil level check is made.
1
1. MAINTENANCE AND LUBRICATION CHART DECAL
85
