INSTRUMENTS/CONTROLS
GROUP 5 2. DIFFUSERS / DEFROSTER / AIR CONDITIONER
CAB The cab provides operator comfort in any ambient condition.
4
1
4
1. DOOR Turning the handle (1), the door opens. To keep the door opened while operating the machine or servicing cab, open the door until it reaches the automatic lock.
4
2 The air deflectors and the fan (4) that are located inside the cab have the function to circulate the air in the cab and to serve also as defrosters for the front and rear windshields.
3
The upper outlet vents (4) have adjustable grille to direct the air flow. Pull lever (2) to release the automatic lock. This lever is located inside the cab, to the operator’s left. The lower outlet vents (3) rotate 360° and have adjustable grille to direct the air flow and increase operator’s comfort.
56
