ELECTRICAL SYSTEM
TRANSMISSION AUXILIARY SYSTEM COME-HOME The COME-HOME is an emergency function, used in event of failure of the transmission control module. If the immediate replacement of the module is not possible, this function allows the driving of the machine to the nearest repair shop. The switch (8) on the instrument panel is a threeposition switch: forward, neutral and reverse. To enable the system, turn off the machine, apply the parking brake and put the switch in the neutral position. Open the cover on the right hand side of the operator’s cab. This allows the access to two gray connectors and one black connector.
COME-HOME ACTIVATED
Close the side-cover, be sure the parking brake is applied, then start the engine. NOTE: After releasing the parking brake, select the desired driving direction (forward - reverse) through the COME-HOME switch on the instrument panel. Moving the COME-HOME switch to the “forward” position the system will select the second forward gear. Moving the COME-HOME switch to the “reverse” position, the system will select the first backup gear. WARNING: The inching pedal
!
SIDE COVER
1
does not function when the COME-HOME mode is activated.
After repairs, reconnect the connectors to their former positions. Connect the connector 1 with connector 2 and connector 3 with connector 4.
3
2 4
COME-HOME NOT ACTIVATED
Disconnect the gray 1 and 2, 3 and 4 connectors. Then connect the 2 and 3 connectors.
134
