1650K
79
Replacing the transmission/converter delivery filter 1. Clean the support base and the surrounding area. 2. Loosen filter F2 and replace it with a new one. Before installing the new filter, lubricate the gasket with engine oil, then screw it on the support. 3. After the gasket touches the base, tighten the filter 3/4 turn further. The tightening must be done exclusively by hand.
WARNING Do not run the engine of this machine in closed areas without proper ventilation to remove deadly exhaust gases. Make sure exposed personnel in the area of operation are clear of the machine before moving it or its attachments. WALK COMPLETELY AROUND the machine before mounting. Sound horn.
WARNING Avoid environment pollution. The used fluids, such as hydraulic oil, lubricants, coolants and the filter elements soaked with these fluids, must be eliminated according to local or national current regulations qualifying these materials as polluting, harmful and dangerous waste.
F2
1850-2M0129
F2. Transmission/torque converter oil filter (delivery)
Oil refilling Retighten plug T on the machine, after cleaning it and fill with oil through filler neck B up to the level on the upper mark, etched on the oil dipstick. Start the engine and run it for a few minutes. Shut-off the engine and after a few minutes, top-off the oil in the circuit, always checking as described at point (2) of the MAINTENANCE TABLE.
D150-2M109
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
