74
1650K
10. BLADE CYLINDER LINKAGE PIVOTS Grease pivots
11. RIPPER LINKAGE PIVOTS Grease pivots
Pump grease into the lube fittings of the blade cylinder support.
Pump grease into the fittings of the ripper linkage. The black arrows indicate that the same fittings are located on the opposite side as well.
WARNING Stop the machine in accordance with the procedures prescribed in the Operation and Maintenance Manual, prior to lubricating or performing any intervention. Always lower the equipment to the ground prior to performing any type of maintenance operation.
D150-2M096
1650-2M038
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
