PIVOT PINS Inspection And Maintenance Figure 370
2 3
1
2 1
3 P-91983A
Dealer Copy -- Not for Resale
The pivots and cylinders (Item 1) have a large pin held in position with a bolt (Item 2) and double nuts (Item 3) [Figure 370] securing the pin. The two nuts (Item 3) are used as locknuts to hold the bolt (Item 2) with out tightening the bolt (Item 2) to the pin boss. After the nuts (Item 3) are tightened together, the bolt (Item 2) should be free to spin. See your Bobcat dealer for replacement parts.
