OPERATING PROCEDURE (CONT’D) Boom Swing Figure 186
Figure 189
NA1433B
NA1432
The boom swing allows the operator to offset the boom and dig close to buildings and other structures [Figure 189].
NA1420B
Figure 188
NA1434B
Slew the upperstructure, swing the boom to the right [Figure 186], center [Figure 187] and left [Figure 188] to dig a square hole the width of the machine without repositioning the excavator.
