5.
Slide the hard disk drive frame to the right and then gently move it inward to detach it from the lower case.
6.
Remove the four screws as shown and then detach the hard disk drive from the frame.
Removing the DIMM
57
1.
See “Opening the Housing” on page 51
2.
See “Removing the FDD and DVD Frame” on page 53”
3.
To release the system memory, press down and out on the levers on both sides of the DIMM socket.
4.
Gently pull the DIMM out of the socket.
Chapter 3
