Standard CMOS Features Select Standard CMOS Features from the main menu to configure some basic parameters in your system. The following screen shows the Standard CMOS Features menu:
The following table describes the parameters found in this menu. Settings in boldface are the default and suggested settings.
Parameter Date
Description Lets you set the date following the weekdaymonth-day-year format
Options Weekday: Sun, Mon...Sat Month: Jan, Feb...Dec. Day: 1 to 30 Year: 1980 to 2079
Time
Lets you set the time following the hour-minutesecond format
Hour: 0 to 23 Minute: 0 to 59 Second: 0 to 59
IDE Primary Channel Master
Allows you to configure the hard disk drive connected to the master port of IDE channel 1.
IDE Device Model Number: None
To enter the IDE Primary Master setup, press [Enter]. The IDE CD-ROM is always automatically detected. IDE Primary Channel Slave
Allows you to configure the hard disk drive connected to the slave port of IDE channel 1.
IDE Device Model Number: None
To enter the IDE Primary Slave setup, press [Enter]. The IDE CD-ROM is always automatically detected.
29
Chapter 2
