BIOS Flash Utility The BIOS flash memory update is required for the following conditions: •
New versions of system programs
•
New features or options
•
Restore a BIOS when it becomes corrupted.
Use the Phlash utility to update the system BIOS flash ROM. NOTE: Create a Crisis Recovery Media (such as USB HDD) before you use the Phlash utility. NOTE: Do not install memory-related drivers (XMS, EMS, DPMI) when you use the Phlash. NOTE: Please use the AC adaptor power supply when you run the Phlash utility. If the battery pack does not contain enough power to finish BIOS flash, the system will not boot as the BIOS is not loaded. Perform the following steps to use the Flash Utility: 1.
Press F2 during boot to enter the Setup Menu.
2.
Select Boot Menu to modify the boot priority order, for example, if using USB HDD to Update BIOS, move USB HDD to position 1.
Information
Main
Security
PhoenixBIOS Setup Utility Boot Exit Item Specific Help
Boot priority order: 1: USB HDD: ABC 2: IDE 0: TOSHIBA MK3252GSX-(S1) 3: IDE 1: ST9160310AS-(S2) 4: IDE CDROM: Optiarc DVD RW AD-7560S-(P 5: PCI LAN: Atheros Boot Agent 6: USB FDD: 7: USB FDD: 8: USB KEY: Excluded from boot order: 3.
Keys used to view or configure devices: Up and Down arrows select a device. <F6> and <F5> moves the device up or down. <x> exclude or include the de ice to boot
Execute the IFLASH.BAT batch file to update BIOS (Read xxxxx.fd to Memory).
Chapter 2
35
