Boot This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices includes the USB diskette drives, the onboard hard disk drive and the DVD drive in the module bay.
Information
Main
Security
PhoenixBIOS Setup Utility Boot Exit Item Specific Help
Boot priority order: 1: IDE 0: TOSHIBA MK3252GSX-(S1) 2: IDE 1: ST9160310AS-(S2) 3: IDE CDROM: Optiarc DVD RW AD-7560S-(P 4: PCI LAN: Atheros Boot Agent 5: USB HDD: 6: USB FDD: 7: USB KEY: 8: USB CDROM: Excluded from boot order:
F1 Help ESC Exit
Chapter 2
↑↓ Select Item ←→ Select Menu
F5/F6 Change Values Enter Select XSub-Menu
Keys used to view or configure devices: Up and Down arrows select a device. <F6> and <F5> moves the device up or down. <x> exclude or include the device to boot.
F9 Setup Defaults F10 Save and Exit
33
