2.
Using a flat blade screw driver, rotate the CPU screw 180° clockwise to lock the CPU into the socket.
Replacing the Thermal Module IMPORTANT: Ensure all heat pads are in place before replacing the Thermal Module. The following thermal pads are approved for use: •
114
Eapus XR-PE
1.
Remove all traces of thermal grease or pad adhesive from the CPU and thermal module using a lint-free cloth or cotton swab and Isopropyl Alcohol, Acetone, or other approved cleaning agent.
2.
Place the pads as shown.
Chapter 3
