Hardware Specifications and Configurations Processor Item
Specification
CPU type
Intel® Core™2 Duo mobile processor, supporting Intel® 64 architecture
Core logic
Mobile Intel® GM45/PM45 + ICH9M
CPU package
Socket M (FCPGA6)
CPU core voltage
1.0375V to 1.3V
CPU Fan True Value Table CPU Temperature Core 0
Fan Speed (rpm)
Core 1
SPL Spec (dBA)
58
58
2500
29
66
66
3000
31
74
74
3400
34
85
85
3800
37
100
100
4200
40
•
Throttling 50%: On= 100°C; OFF=90°C
•
OS shut down at 105°C; H/W shut down at 96°C
BIOS Item
Specification
BIOS vendor
Insyde
BIOS Version
1.00 (MP version)
BIOS ROM type
Macronix_MX25L8005/ EON_EN25F80
BIOS ROM size
1M bytes
BIOS package
SPI Flash part
Supported protocols
ACPI 1.0b/2.0/3.0 PCI 2.2 or later System/HDD Password Security Control INT 13h Extensions PnP BIOS 1.0a SMBIOS 2.4 or later· BIOS Boot Specification (Compal, Phoenix, Intel) Simple Boot Flag 1.0 Boot Block PCI Bus Power Management Interface Specification USB Specification 1.1/2.0 USB Boot Up support Support HD audio WfM 2.0 Preboot Execution Environment (PXE) 2.1 Boot Integrity Service Application Program Interface (BIS) 1.0· PC2002/2005 compliant Intel Enhanced SpeedStep Technology AHCI support.
BIOS password control
Set by setup manual
