Removing the Keyboard 1.
Open the notebook as shown.
2.
Remove the middle cover. Though it is combined tightly, detach it from the main unit carefully. Do not pull it abruptly.
3.
There are four latches securing the keyboard.
4.
Push those latches by the screw driver as shown and the keyboard will pop up a little.
5.
Remove the keyboard and reverse it.
6.
Carefully pull the keyboard FFC lock, then disconnect the keyboard FFC.
Chapter 3
63
