01 Engine 01 15 Rotating parts
Removing the rear bearing gasket – Fit and centre tool No.60 0500 550 9 on the rear end of the crankshaft. Then use stop ring pliers and place the narrow shoulder of the tool ring (B) behind the edge of the inner gasket cage.
A
– Hold the parts assembled using a clamp (C), then tighten the screw (D) slowly until the inside cage of the joint is extracted.
B
C
D
Fig. 53
121hsm64
– Using a punch and a hammer, push the outer gasket cage towards the engine until the outer cage rotates. – Extract the seal cage (F) using a slide hammer.
F 121msm27
Arion 430-410 – 01.2010 – GB
Fig. 54
63
